X-Sight HT
Let's heat it up!

X-Sight HT

A brand new video extensometer for temperatures up to 1400°C based on the latest Digital Image Correlation technology reaching the state of the art. The hardware device HT is today's most Xsighting device for high-temperature strain measurement

The HT combines high-precision measurement together with a user friendly graphic interface to keep the focus on the experiment during uniaxial or biaxial tensile, compression and shear testing.

The HT can be used not only with furnaces, but anywhere a high precision on small Field of View is needed.

Specification

  • Measurement length: 47mm
  • Resolution ISO9513: Class 0.2
  • ASTME83-10: Class A ( GL > 15mm )
  • Gauge Length: Selectable single or multiple gauge lengths
  • Data acquisition rate: 75-200Hz
  • From ambient to 1400°C
  • Axial and radial neck detection
  • Lighting: Auto-switching monochromatic light
